UNVS01 FEATURES
SPECIALIZED TREAD COMPOUND
This innovative tread compound works at the molecular level to reduce friction heat build-up, achieving performance balance between high wear and low rolling resistance.
SHOULDER LUG GROOVES
Shoulder Lug Grooves promote even wear, which reduces shoulder heat generation, extends the life of the tire and increases profitability
LOW ROLLING RESISTANCE
The closed shoulder design reduces irregular wear and rolling resistance, to improve fuel efficiency.
DEEP TREAD DEPTH
The Deep Tread Depth of 28/32nds, built to grab the road, works hand-in-hand with our Specialized Tread Compound and extends the life of the tire.
ZIG ZAG GROOVES
Four main zig-zag grooves provide better traction performance for dry and wet conditions.
CONTROL STRIPS
The substantial rubber strips on each side of the vertical ribs give drivers braking confidence when hauling heavy loads.
STONE EJECTORS
Stone ejectors protect the body by expelling stones and not allowing them to be trapped in the bottom of the groove.
FOUR-BELT REINFORCEMENT
Within the tire construction, four belts and a belt cushion effectively improve tire load maneuverability and endurance.
RELATED VIDEOS
SIZES
| ARTICLE | SIZE | LOAD ID | PLY RATING | RIM WIDTH | TREAD DEPTH 32nds | TREAD WIDTH |
MAX LOAD SINGLE|DUAL |
WEIGHT |
|---|---|---|---|---|---|---|---|---|
| 841623132293 | 295/75R22.5 | G | 14G | 8.25-9.00 | 28 | 9.06 | 6175 / 5675 | 127.96 |
| 841623131593 | 295/75R22.5 | H | 16H | 8.25-9.00 | 28 | 9.06 | 6610 / 6005 | 127.96 |
| 841623131609 | 11R22.5 | H | 16H | 7.50-8.25 | 28 | 8.66 | 6945 / 6395 | 128.11 |
| 841623131616 | 11R24.5 | H | 16H | 7.50-8.25 | 28 | 8.66 | 7160 / 6610 | 142.60 |
| 841623131623 | 285/75R24.5 | G | 14G | 7.50-8.25-9.00 | 28 | 8.66 | 6175 / 5675 | 131.10 |
